Dell PowerEdge R450

Dell PowerEdge R450 Server

Brand: Dell
Name:Dell PowerEdge R450
Model: Dell R450 4LFF Server – Dell PowerEdge R450 Server
Details:  Dell R450 4LFF Server. Note: Estimated delivery time is in one week
Availability:  yes
Condition: Used
Shipping: All over Pakistan
Price: Price on “WhatsApp” or “Call“.
Categories: , , , , ,
Price on Request

Contact our team for current pricing, availability and configuration options.

Available on request

Overview

Brand: Dell Name:Dell PowerEdge R450 Model: Dell R450 4LFF Server - Dell PowerEdge R450 Server Details:  Dell R450 4LFF Server. Note: Estimated delivery time is in one week Availability:  yes Condition: Used Shipping: All over Pakistan Price: Price on "WhatsApp" or "Call".

Talk to an equipment specialist

Confirm stock, lead time, compatibility and volume pricing with our team.

Request Pricing
Add to quote
Ask on WhatsApp Email for Pricing
Add to quote

Description

Dell PowerEdge R450 Server Overview

The Dell PowerEdge R450 Server, with 3rd generation Intel® Xeon® Scalable processors, offers improved performance and exceptional value in a 1U rack server.

Table 1 shows the 3 configuration of Dell R450 4LFF Server.

Configuration Processor Memory Hard Drive Power Supply
Dell 1U R450 1*4310 4LFF Server 1 * Intel Xeon 4310 1 * 32G 1*2T SAS 10K 1*600W
Dell 1U R450 1*5317 4LFF Server 1 * Intel Xeon 5317 1 * 32G 1*2T SAS 10K 1*800W
Dell 1U R450 1*5320 4LFF Server 1 * Intel Xeon 5320 1 * 32G 1*2T SAS 10K 1*800W

Quick Spec

Table 2 shows the quick spec of Dell R750 server.

Product Code Dell R450 4LFF Server
Processor Up to two 3rd Generation Intel® Xeon® Scalable processors, with up to 24 cores per processor
Operating System (Dell Technologies recommends Windows 11 Pro for business)

Canonical® Ubuntu® Server LTS

Citrix® Hypervisor®

Microsoft® Windows Server® with Hyper-V

RedHat® Enterprise Linux

SUSE® Linux Enterprise Server

VMware® ESXi®
Chipset Intel® C620A chipset
Memory DIMM Speed

Up to 2933 MT/s

Memory Type

RDIMM

Memory Module Slots

16 DDR4 DIMM slots

Maximum RAM

RDIMM 1 TB
Storage Front Bays

Up to 4 x 3.5-inch SAS/SATA (HDD/SSD) max 16 TB

Up to 8 x 2.5-inch SAS/SATA (HDD/SSD) max 7.68 TB

Product Details

The Dell EMC PowerEdge R450 is a two-socket entry-level 1U server offering updated technologies and added value with faster processing speeds and flexible storage options.

Density-optimized general-purpose server

The Dell EMC PowerEdge R450 with 3rd Generation Intel® Xeon® Scalable processors delivers the perfect combination of performance, density, and affordability for general-purpose scale and web-tech deployments.

  •  Supports up to 24 cores per CPU, and up to 16x DDR4 RDIMMs at up to 2933 MT/s
  • Built with a minimum footprint and enterprise computing to fit into a variety of environments
  • Manage with iDRAC9 Enterprise, OpenManage Enterprise and Plugins, iDRAC Direct, and Quick Sync 2.0
  • Full-stack management integration with Microsoft, VMware, ServiceNow, Ansible, and many other tools for on-premises, edge, and cloud environments

Figure 1. Front view of the R450 system

front-view-of-the-r450-system

Figure 2. Rear view of the R450 system

rear-view-of-the-r450-system

Figure 3. In the R450 system

in-the-r450-system

Get More Information

Do you have any questions about the Dell R450 4LFF Server?

Contact us now via “Whatsapp” or “acecommunication@gmail.com”

Dell R450 4LFF Server Specification

Dell R450 4LFF Server Specification
Processor Up to two 3rd Generation Intel® Xeon® Scalable processors, with up to 24 cores per processor
Operating System (Dell Technologies recommends Windows 11 Pro for business)

Canonical® Ubuntu® Server LTS

Citrix® Hypervisor®

Microsoft® Windows Server® with Hyper-V

RedHat® Enterprise Linux

SUSE® Linux Enterprise Server

VMware® ESXi®
Chipset Intel® C620A chipset
Memory DIMM Speed

Up to 2933 MT/s



Memory Type

RDIMM



Memory Module Slots

16 DDR4 DIMM slots



Maximum RAM

RDIMM 1 TB
Storage Front Bays

Up to 4 x 3.5-inch SAS/SATA (HDD/SSD) max 16 TB

Up to 8 x 2.5-inch SAS/SATA (HDD/SSD) max 7.68 TB

Storage Controllers

 Internal Controllers

PERC H345, PERC H355, PERC H745, PERC H755, HBA355i



External Controllers

PERC H840, HBA355e



Software RAID

S150



Internal Boot

Boot Optimized Storage Subsystem (BOSS-S1): HW RAID 2 x M.2 SSDs 240 GB or 480 GB

Internal Dual SD Module or USB
Security Cryptographically signed firmware

Secure Boot

Secure Erase

Silicon Root of Trust

System Lockdown (requires iDRAC9 Enterprise or Datacenter)

TPM 1.2/2.0 FIPS, CC-TCG certified, TPM 2.0 China NationZ

Management

 Embedded / At-the-Server

iDRAC9

iDRAC Service Module

iDRAC Direct

Quick Sync 2 wireless module

Mobility

OpenManage Mobile



Tools

iDRAC RESTful API with Redfish

IPMI

RACADM CLI

System Update Utility

Update Catalogs



OpenManage Integrations

BMC® Truesight

Microsoft® System Center

RedHat® Ansible® Modules

VMware® vCenter and vRealize Operations Manager



OpenManage connections

IBM Tivoli® Netcool/OMNIbus

IBM Tivoli® Network Manager IP Edition

Micro Focus® Operations Manager

Nagios® Core

Nagios® XI

Power Supplies

 1100 W DC -48–(-60) V

800 W Platinum AC/240 V HVDC

600 W Platinum AC/240 V HVDC

Hot plug power supplies with full redundancy option

Up to 7 cold swap fans
Ports Network Options

2 x 1 GbE LOM and 1 x OCP 3.0

Rear Ports

1 x USB 2.0

Internal Ports

1 x USB 3.0
Slots 2 x PCIe Gen4 slots
Bezel Optional LCD bezel or security bezel

Form Factor

 1U rack server

Dimensions & Weight

 Height

42.8 mm (1.68 inches)



Width

482 mm (18.97 inches)



Depth

For 4 x 3.5-inch configuration

748.79 mm (29.48 inches) with bezel

734.95 mm (28.93 inches) without bezel



For 8 x 2.5-inch configuration

698.03 mm (27.48 inches) with bezel

684.19 mm (26.93 inches) without bezel



Weight

For 4 x 3.5-inch system – 18.62 kg (41.05 lbs.)

For 8 x 2.5-inch system – 16.58 kg (36.55 lbs.)
Rack Support ReadyRails™ II sliding rails with optional cable management arm (CMA) and strain relief bar (SRB) for 4-post racks.

Combo (Drop-in/Slide-in) rails with optional CMA and SRB for 4-post racks.

ReadyRails™ static rails for 4-post and 2-post racks.

Recommended Support

 Choose Dell ProSupport Plus for critical systems or Dell ProSupport for premium hardware and software support for your PowerEdge solution. Consulting and deployment offerings are also available. Contact your Dell representative today for more information. Availability and terms of Dell Services vary by region.

Request a Quote for Dell PowerEdge R450 Server – Contact Us for Queries and Assistance

If you have any queries or require further assistance regarding our network accessories or any other products and services, we are here to help. We offer multiple ways to get in touch and make it convenient for you to reach out to us.

Request a Quote:

If you need a customized solution or want pricing information for specific products, we encourage you to use our Request a Quote form. Simply fill in the necessary details, including your contact information and specific requirements, and our team will get back to you promptly with the information you need. Visit “GET A QUOTE” to access the form and submit your request

Contact Us for Queries and Assistance

We are here to assist you! If you have any questions or need further information about our network accessories or any other products and services, please feel free to reach out to us using any of the following methods:

  • Phone: Call us at +92318-0111902.
  • Email: Send us an email at ops@ace-comm.com.
  • Live Chat: Visit our website and use the live chat feature for instant assistance.
  • WhatsApp: Message us directly on WhatsApp at +92 321 8283360.
  • For the datasheet Click here
