Dell PowerEdge C6420
Description
The Dell PowerEdge C6420 is a rack platform from Dell’s PowerEdge family
powered by Up to two Intel® Xeon® Scalable processors, up to 205W and 28 cores per processor, 2 processor socket(s)
.
Key specifications
- Memory: 16 DIMM slots with max of 512GB with options for 8GB/16GB/32GB DDR4 2666MT/s RDIMMs ECC Registered DDR4
- Drive bays: Hard Drives: 300/600/900GB 2.5” 15K 12Gb SAS Drives ; 600GB/1.2TB/1.8TB 2.5” 10K 12Gb SAS Drives ; 1TB/2TB 2.5” 7.2K 12Gb SAS Drives ; 1TB/2TB/4TB/8TB/10TB 3.5” 7.2K 12Gb SAS/ 6Gbps SATA Drives ; Solid State Drives: 120GB 2.5” 6Gbps SATA Boot SSD ; 480GB/800GB/960GB/1.6TB/1.92TB/3.84TB 6Gbps SATA ; Read Intensive SSDs: 960GB/1.92TB/3.84TB 12Gbps SAS Read Intensive SSDs ; FIPS-140 Self Encrypting Hard Drives: 1.2TB 2.5” 10K 12Gb SAS FIPS-140 SED ; 2TB 2.5” 7.2K 12Gb SAS FIPS-140 SED ; 4TB/8TB 12Gbps SAS FIPS-140 SED ; NVMe Drives: 800GB/1.6TB Mixed Use 2.5” NVMe SSDs and PCIe add-in adapter cards
- Power: Dual Hot-plug fault tolerant redundant and non-redundant 1600W AC Power Supply ; Dual Hot-plug fault tolerant redundant 2000W and 2400W AC Power Supply ; Four dual rotor redundant, non-hot swappable fans ; Air and Direct Contact Liquid Cooling (DCLC) options
- Dimensions: Dimensions (HxWxD) 86.8mm x 448mm x 790mm ; Weight 3.5” Direct Backplane Chassis: 43.62 Kg ; 2.5” Direct/Expander/NVMe Backplane Chassis: 41.46 Kg ; No Backplane Chassis: 34.56 Kg ; Form factor: Rack (2U) 24 x 2.5” Direct Backplane with up to 6 SAS/SATA drives per C6420 sled ; 24 x 2.5” Expander Backplane with up to 12 SAS/SATA drives per C6420 sled and 2 C6420 sleds per C6400 chassis ; 24 x 2.5” NVMe Backplane with up to 2 SAS/SATA/NVMe drives and 4 SAS/SATA drives per C6420 sled ; 12 x 3.5” Direct Backplane with up to 3 SAS/SATA drives per C6420 sled ; No Backplane option with no external drives per C6420 sled
Every configuration is built to order: choose your processor, memory, storage and accessories, and our team will confirm pricing and availability for Pakistan. Ace Communication supplies genuine Dell products with manufacturer warranty and local support from our Karachi office.
Price on request — contact us on WhatsApp or call 021-34999444 for the latest price and delivery time.
Additional information
| Product Solution | cloud-servers |
|---|---|
| Form Factor | Rack |
| CPU Manufacturer | Intel |
| CPU Type | intel-xeon-series |
| Processor | Base — Up to two Intel® Xeon® Scalable processors, up to 205W and…, Performance — Intel Xeon Series (upgrade), Max — Intel Xeon Series (top bin) |
| Memory | 32GB, 64GB, 128GB, 256GB |
| Storage | NVMe SSD — 480GB, NVMe SSD — 960GB, NVMe SSD — 1.92TB, NVMe SSD — 3.84TB |
| Accessories | Rail kit, Redundant power supply, iDRAC Enterprise license, Extended warranty, 10GbE / 25GbE network adapter, GPU kit (where supported) |
